469-P5-HI-A20-E-H-5 Generator Management Relay
دليل المنتج：
469-P5-HI-A20-E-H-5 Generator Management Relay is an intelligent protection and management device used for generators and backup power systems. It is usually installed in the generator control system to monitor, protect, and control the operating status of the generator. It can collect real-time electrical parameters of the generator and provide alarms or action control according to the set logic, ensuring the safe and stable operation of the generator.
1、 Product Overview
This relay integrates multiple protection functions, which can monitor the voltage, حاضِر, frequency, and load status of the generator in real time, and provide automatic switching, alarm, and protection actions. Suitable for places such as industrial, commercial, and power stations that require reliable generator management.
2、 الوظائف الرئيسية
Generator overcurrent, overvoltage/undervoltage, and underfrequency protection
Phase sequence, phase imbalance, and phase loss detection
Automatic start/stop and load management functions
Fault alarm and remote communication interface
Support multiple generator control logics and customized functions
Provide reliable relay output signals for controlling external devices
3、 Technical parameters (typical)
نموذج: 469-P5-HI-A20-E-H-5
Working voltage: AC/DC 24-240 V
Input signals: الجهد االكهربى, حاضِر, frequency
Output: Relay contact output
Action accuracy: ± 1%
Response time: ≤ 20 ms (typical)
Working temperature: -20 ℃~+70 ℃
Installation method: Panel or rack installation
Protection level: IP20/IP54 (depending on installation method)
4、 Product Features
Multi functional integrated protection reduces the need for external relays
Intelligent logic control, supporting automated management
High reliability design, suitable for industrial environments
Support remote monitoring and alarm functions
Modular design, easy to maintain and upgrade
469-P5-HI-A20-E-H-5 صور مفصلة للمنتج：
469-P5-HI-A20-E-H-5 فيديو المنتج
