EG1033AA EG1033AA01 flame amplifier

دليل المنتج：

EG1033AA/EG1033AA01 flame amplifier
Product positioning

Flame Monitoring Module in Industrial Combustion Control System

Used to detect the flame state of the burner and output safety control signals

Commonly used in boilers, gas stoves, and industrial heating equipment

core functionality

Real time monitoring of flame presence status

Amplify and convert the flame signal into a standard control signal output

Provide safety interlock signals to the combustion control system

Support fault diagnosis and alarm functions to improve equipment safety

Technical Features

High sensitivity flame detection, استجابة سريعة

تصميم الصف الصناعي, high temperature resistance, vibration resistance, and electromagnetic interference resistance

Output signal compatible with commonly used industrial control system interfaces

Compact modular structure, easy to install and replace

working principle

Flame sensor detects burner flame light signal

The signal is transmitted to the flame amplifier for amplification and filtering processing

The module outputs the processed signal to the combustion control system

The control system performs burner start stop or safety interlock based on the flame state

EG1033AA EG1033AA01 صور مفصلة للمنتج：

EG1033AA EG1033AA01 فيديو المنتج
