SY-1025115C SY-1025120E 0399143 SY-0301060R Combined Control Panel

Product Manual：

1、 Combination description

0399143 + SY-0301060R + SY-1025115C + SY-1025120E
It belongs to a combination control board component in an industrial control system, mainly used for power supply and system connection.

It is not a single board, but a complete functional unit formed by the combination of multiple components.

2、 Functional division of each component
one ️⃣ SY-0301060R (power module)

Provide stable DC power supply (usually 24VDC)

Support redundant operation (dual power parallel)

Equipped with overvoltage and overcurrent protection

It is the core power supply unit of the entire system

two ️⃣ SY-1025115C (redundant connection line)

Used to connect two power modules

Realize power redundancy switching

Ensure continuous operation of the system in the event of a single power failure

three ️⃣ SY-1025120E (Backplane Adaptation Module)

Used for connecting power supplies to system racks

Transmission of power and status signals

Provide installation and interface support

four ️⃣ 0399143 (kit number)

Indicate the order number for the entire set of combinations

Generally includes: power module+cable+interface module

Used for overall procurement and system integration

3、 Main functions

Stable power supply for the control system

Implement power redundancy (improve reliability)

Support non-stop switching

Provide system operation status monitoring

4、 Technical features

Wide input voltage range (suitable for industrial power grid)

Stable output (suitable for DCS/PLC systems)

Support hot plugging (some models)

Industrial grade design, strong anti-interference ability

Long term continuous stable operation

5、 Typical applications

Power plant control system

Petrochemical automation

Industrial production line control

Water Treatment and Energy Systems

6、 Brief Summary

The essence of this combination is:
Redundant power supply and interface integration components in industrial control systems, used to ensure stable system operation
