6GT2002-0AB00 Printed Circuit Board

دليل المنتج：

1、 المعلومات الأساسية
نموذج: 6GT2002-0AB00 (ASM 410 coupler motherboard)
Brand/Series: Siemens SIMATIC NET MOBY-I
Function: RFID coupler core PCB, responsible for signal processing, تواصل, and logic control
Compatible devices: compatible with MOBY-I read-write heads (ASIM 400/401/500)
Status: Discontinued (EOL), mainly for maintenance and replacement
2、 Core parameters
Power supply: DC 24 V (20-30 V)
Power consumption: عادي 2 دبليو
Processor: 8 KB RAM/2 KB Flash
واجهة الاتصالات: PROFIBUS-DP, رس-485
Temperature: 0 ° C~+55 ° C (working)
Size/Weight: Standard Eurocard Size/Approximately 150g
Board: Industrial grade FR-4, with shielding and three proof coating

3、 Key functions
Main control and signal processing: The MOBY-I system core processes RFID read-write signals, encoding and decoding, and verification.
Bus communication: PROFIBUS-DP slave station, connected to S7-300/400 PLC, with a speed of 9.6 kbps -12 Mbps.
Read/write head driver: drives ASIM 400/500 antennas, supports multi tag recognition, and high-speed data exchange.
Diagnosis and Status: Onboard LED indicator light, fault self-test, communication status display.
Industrial reliability: مكافحة التدخل, مقاوم للغبار والرطوبة, earthquake resistant, suitable for harsh environments on production lines.

صور مفصلة للمنتج：

6GT2002-0AB00
