ضخم 0100-02355 وحدة الواجهة
دليل المنتج：
ضخم 0100-02355 SCR Interface Module
مقدمة: ضخم 0100-02355 is a semiconductor machine specific SCR thyristor drive interface board, responsible for power regulation signal transmission, and is a spare part for maintenance of deposition/sputtering equipment.
0100-02355 is responsible for the signal relay between the main control and SCR power module
Optoelectronic isolation circuit, isolating high-voltage electromagnetic interference and protecting the main control board
Multi channel DB serial port, gold finger terminal, compatible with power unit wiring
Built in filtering circuit to suppress clutter and avoid power output fluctuations
Onboard status indicator light, quickly locate communication and voltage regulation faults
Multi layer precision power wiring, carrying high current signal transmission
Independent circuit overcurrent and short circuit protection to prevent power devices from burning out
Industrial grade temperature resistant components, supporting 7 × 24-hour continuous process
Standard chassis card insertion version, no need to change wiring for disassembly and replacement
Metal shielding shields the power area and reduces plasma interference in the cavity
ثلاثة طلاء مقاوم على سطح اللوحة, مقاوم للغبار والرطوبة, suitable for dust-free clean workshops
Real time feedback voltage regulation sampling signal, stable power closed-loop control
Adapt to AMAT thin film deposition platforms such as Centura and Endura
Factory electrical calibration, directly matched with SCR power unit on the machine
Standard hole position connector, directly interchangeable and compatible with the same model
خاتمة: ضخم 0100-02355 is used for temperature control/power adjustment of sputtering and annealing equipment, with stable operation and strong versatility for replacement.
صور مفصلة للمنتج：
0100-02355
