ضخم 0190-43361 لوحة الدوائر المطبوعة

دليل المنتج：

ضخم 0190-43361 printed circuit board is a signal board for AMAT thin film equipment. The AMAT 0190-43361 printed circuit board is responsible for vacuum pressure signal transmission. There are 15 product features:
High temperature resistant multi-layer board, the cabinet is not easily deformed after long-term operation
Partition the wiring of strong and weak lines to reduce signal interference with each other
Sinking gold solder pad, anti-oxidation contact, stable and durable
Multi channel sensor signal acquisition circuit, real-time feedback of vacuum parameters
Large area grounding copper layer, shielding cavity RF clutter
High and low voltage line isolation, insulation safety meets standards
Simple short-circuit protection circuit to prevent board burnout

Equipped with filtering components to reduce fluctuations in pressure measurement values
Original standard socket, easy to disassemble and assemble wiring harness
Dense thermal conductive vias reduce component operating temperature rise
Compact layout, توفير مساحة التثبيت داخل الخزانة
Wide temperature adaptation production line, stable operation of constant temperature workshop
Fully automatic SMT process, with firm solder joints and minimal virtual soldering
Moisture resistant solder mask coating, suitable for clean room environment
Complete electrical testing at the factory and direct replacement for use on the machine
ضخم 0190-43361 Printed Circuit Board Compatible with PVD/CVD Machine, Used for Vacuum Testing System Repair and Replacement of PCB Accessories

صور مفصلة للمنتج：

0190-43361
