BOBST 701-1264F Relay Board

دليل المنتج：

BOBST 701-1264F Relay Board
BOBST 701-1264F is a relay output board specifically designed for die-cutting machines, belonging to the old 701 series I/O board. It has been discontinued by the original factory and is responsible for converting low-voltage control signals into strong electrical execution drives.
lass=”yoast-text-mark” />>Original part number: 701-1264F (701 series standard relay board)
Board positioning: die-cutting machine load drive/switch output board, controlling solenoid valves, المحركات, أضواء المؤشر, safety circuits
Compatible models: BOBST 733, SP series flat die-cutting machine (with 701 control system)
PCB material: FR-4 flame retardant fiberglass board, double-layer layout, vibration and temperature resistance
Relay configuration: Integrated multi-channel power relay, contact capacity 5A/250VAC, with continuous current protection
Control mode: 24VDC coil drive, photoelectric isolation, complete isolation of strong and weak electricity
Output type: normally open/normally closed contacts, suitable for inductive/resistive loads

Power supply specification: 24VDC ± 15%, onboard voltage stabilization and reverse protection
Protection mechanism: self recovering fuse, TVS surge protection, contact RC absorption
Connector: Edge gold finger+European style terminal, reliable insertion and removal, anti-oxidation
Installation size: Standard 701 series card slot, in situ replacement without modification
Working environment: -10 درجه مئوية~+60 درجه مئوية, suitable for workshop oil pollution and dust environment

صور مفصلة للمنتج：

701-1264F
