BOBST 704-1091-04 Display Interface Board
دليل المنتج：
BOBST 704-1091-04 display interface board, dedicated human-machine interface adapter board for Bost 704 series die-cutting machines.
Transfer master control data, transmit operating parameters and fault codes to the operation display screen
Receive panel button commands and transmit signals back to the main control unit of the entire machine
Onboard signal isolation circuit, isolating workshop frequency conversion interference and preventing garbled images
Gold plated finger card slot installation, quick replacement through direct insertion of the cabinet
Equipped with a built-in status indicator light, it can intuitively troubleshoot communication disconnection faults
PCB three proof coating, مقاوم للغبار والرطوبة, suitable for paper processing conditions
Component reinforcement welding, resistant to equipment reciprocating vibration
Industrial wide temperature devices, stable operation in workshop temperature difference environment
Reserved test contacts, on-site multimeter maintenance signal voltage
10. Built in filtering circuit to filter out line clutter interference
11. Strong and weak electrical zoning wiring to avoid high and low voltage signal crosstalk
12. Integrated over-current and over-voltage protection, single circuit failure does not damage the entire board
13. Multiple sets of terminal interfaces, respectively connected to the LCD screen and operation button board
14. Perfectly match the old Bosch 704 electronic die-cutting and box pasting models
15. Factory power on aging test, equipment maintenance stock replacement parts
إنهاء
إجمالي, 704-1091-04 has stable communication and high adaptability, making it the preferred replacement spare part for equipment display screen failures.
صور مفصلة للمنتج：
704-1091-04
