COMPACTPCI SC2650-4-S Control Board
دليل المنتج：
COMPACTPCI SC2650-4-S Control Board
مقدمة: COMPACTPCI SC2650-4-S is a dedicated CPCI control board for TEL semiconductor equipment, responsible for overall operation and signal management, and adapting to long-term stable production of etching machines.
Standard 3U CompactPCI specification, compatible with machine standard backplane slot
Multi channel network communication channel for fast transmission of process operation data
Onboard independent computing chip, real-time processing of device control instructions
Optocoupler isolation circuit to isolate high and low voltage signals from interfering with each other
Multi layer high-density PCB wiring with low signal transmission loss
Built in multiple circuit protection against overcurrent, ماس كهربائى, and overvoltage
Wide temperature industrial components, suitable for clean workshop temperature difference environment
Reinforced surface mount welding, less prone to virtual welding and circuit breaking due to machine vibration
Comes with local storage, caching faults and process operation logs
Multiple IO expansion interfaces, compatible with various sensing and execution components
Metal shielding layer design to resist electromagnetic clutter interference in the workshop
دعم الاستبدال الساخن القابل للتبديل, maintenance does not require the entire machine to be shut down or powered off
Full board anti-corrosion solder mask coating, resistant to trace chemical gases in clean rooms
Reserve multiple sets of testing points to quickly troubleshoot line faults
Factory complete aging testing, 7 × 24-hour continuous operation with low faults
خاتمة: COMPACTPCI SC2650-4-S has stable computing and communication performance and is the core control unit of semiconductor equipment, effectively reducing the frequency of production line downtime and maintenance.
صور مفصلة للمنتج：
SC2650-4-S
