DS200FCGDH1BBA PCB circuit board
دليل المنتج：
#DS200FCGDH1BBA PCB circuit board
1. Output thyristor SCR gate control trigger signal to control the triggering timing of power rectification unit.
2. Adapt to the turbine control rack, connect to the backplane bus and processor card for data exchange.
3. Receive instructions from the main control and allocate trigger signals to each power branch channel.
4. Collect feedback on the voltage and current of the power circuit, process it, and send it back to the main control unit.
5. Three proof coating PCB board can withstand high temperature, اهتزاز, and strong electromagnetic interference environments in power plants.
6. ضوء مؤشر الحالة على متن الطائرة, visually displaying the working status of the trigger channel and feedback loop.
7. Equipped with hardware self-test, it can quickly detect faults and anomalies in triggering and feedback channels.
8. Adapt LCI load commutation inverter to process multiple sets of power interface signals.
9. هيكل الفتحة القياسية, من السهل توصيله, تفكيك, والمحافظة عليها.
10. Connect the six pulse phase controlled rectifier bridge as a signal intermediary board for the power unit.
11. Can operate in conjunction with system redundancy mode to ensure stable power control.
12. The signal processing delay is small, meeting the real-time triggering requirements of the excitation power unit.
13. Collect the operating status of the bridge arm and report alarm and fault information to the main control.
14. The compact size of the board saves installation space inside the rack.
15. Malfunctions can be directly replaced with the entire machine, reducing the downtime for unit maintenance.
This DS200FCGDH1BBA PCB circuit board is used for power generation turbine industrial control systems, mainly responsible for SCR thyristor gate control triggering and power circuit signal acquisition and feedback.
صور مفصلة للمنتج：
DS200FCGDH1BBA
