JEOL AP002104-00 processor board

دليل المنتج：

The JEOL AP002104-00 processor board is compatible with the JSM-6701F scanning electron microscope and serves as an independent computing unit for the equipment subsystem.
1. Original factory board, matched with JEOL JSM-6701F field emission scanning electron microscope control system
2. Share the computational pressure of the main control and independently handle subsystem related tasks
3. Analyze control instructions and issue drive signals to supporting components
4. Preprocess sensor data collection and upload it to the main control module
5. Partition wiring, weaken high-frequency signal interference, and ensure imaging stability
6. Slot style installation, من السهل تفكيكها واستبدالها

7. Built in electrostatic protection circuit to protect the core chip
8. تصميم التدريع الكهرومغناطيسي, suitable for complex laboratory environments
9. Industrial grade components that support long-term continuous operation of equipment
10. Real time collection of component operating parameters and synchronous feedback of working status
11. Equipped with fault diagnosis, quickly identify communication abnormalities
12. Equipped with surge and overvoltage protection to reduce the risk of hardware damage
13. The substrate has strong stability and is less affected by temperature and humidity changes
14. Line partition layout for easy maintenance and troubleshooting
15. Pre calibration at the factory, simple verification required for installation
The JEOL AP002104-00 processor board is responsible for data computation and real-time control of the local subsystem of the scanning electron microscope.

صور مفصلة للمنتج：
