جيول AP002109-00 لوحة الدوائر المطبوعة

دليل المنتج：

JEOL AP002109-00 printed circuit board is compatible with JSM-6701F field emission scanning electron microscope as a subsystem signal transfer and conditioning substrate.
1. Original PCB components, matched with JEOL JSM-6701F scanning electron microscope system
2. Undertake the transfer and transmission of multiple control signals and sensing signals
3. Precision impedance wiring reduces signal attenuation and waveform distortion
4. The insulation performance of the board is excellent, preventing circuit leakage and short circuit
5. Optimize routing layout to reduce signal cross interference
6. Slot fixed structure, من السهل تفكيك واستبدال العملية
7. Board surface anti-oxidation coating, resistant to laboratory moisture and dust

8. Equipped with basic electrostatic protection to protect external components
9. Reliable through-hole process, long-term operation is not prone to poor contact
10. Connect various functional units to achieve data exchange between modules
11. Reserve filtering points to weaken the impact of clutter on imaging performance
12. Line partition isolation to prevent high and low voltage circuits from affecting each other
13. Good environmental adaptability, stable operation under temperature and humidity fluctuations
14. Clear point identification for easy maintenance and inspection of circuit continuity
15. Strict dimensional accuracy, direct replacement without changing the rack
The JEOL AP002109-00 printed circuit board is used for signal exchange and line transfer between various functional boards inside the scanning electron microscope.

صور مفصلة للمنتج：
