JEOL AP002268-00 processor board

دليل المنتج：

JEOL AP002268-00 processor board is compatible with JSM-6701F scanning electron microscope, responsible for subsystem data computation and instruction scheduling.
1. Original factory board, matched with JEOL JSM-6701F field emission scanning electron microscope
2. Receive master control instructions and ensure the orderly operation of supporting functional units for management and control
3. Real time processing of sensor collected signals to ensure stable timing of equipment
4. Precise wiring to reduce signal crosstalk and avoid affecting imaging quality
5. Built in signal filtering circuit to suppress clutter noise
6. Slot installation, التفكيك والاستبدال سهل وسريع

7. Anti static protection, protecting onboard computing chips
8. Electromagnetic shielding structure, suitable for laboratory electromagnetic environment
9. Industrial grade components that support long-term continuous operation of instruments
10. Responsible for data exchange between modules and forwarding control signals
11. مجهزة بوظيفة التحقق الذاتي من الخطأ, providing timely feedback on abnormal working conditions
12. Integrated multiple overvoltage and overload circuit protection
13. The substrate is stable and can withstand fluctuations in environmental temperature and humidity
14. Clear line zoning for easy troubleshooting and maintenance
15. Accurate dimensional tolerance, direct replacement without complex calibration
The JEOL AP002268-00 processor board serves as the domain control core and collaborates with the motherboard to complete various control tasks for scanning electron microscopy.

صور مفصلة للمنتج：

AP002268-00
