JEOL AP002380-01 Control Board

دليل المنتج：

JEOL AP002380-01 control board is compatible with JSM-6701F scanning electron microscope and is responsible for closed-loop control of auxiliary functional units.
1. Original components, compatible with JEOL JSM-6701F field emission scanning electron microscope
2. Receive instructions from the main control and manage the operation status of supporting electromechanical components
3. Collect feedback signals from various sensors to achieve real-time closed-loop control
4. Signal zoning routing reduces line crosstalk and ensures stable imaging
5. Equipped with signal filtering circuit to suppress circuit clutter interference
6. هيكل الفتحة القياسية, easy and efficient disassembly and replacement
7. Built in static discharge circuit to protect onboard chips

8. Electromagnetic shielding treatment, adapted to laboratory electromagnetic environment
9. Industrial grade components that support long-term continuous operation of instruments
10. Real time upward feedback on component operating parameters and status
11. Capable of basic fault self checking and quickly reporting signal abnormalities
12. Integrated overcurrent and overvoltage protection to avoid hardware damage
13. The substrate is resistant to temperature and humidity changes, and has stable performance during long-term operation
14. Clear line markings for easy maintenance and troubleshooting
15. Factory pre calibration completed, with minimal installation and debugging workload
The JEOL AP002380-01 control board is responsible for driving control and status signal interaction of the scanning electron microscope auxiliary mechanism.

صور مفصلة للمنتج：

AP002380-01
