JEOL BP101502-01 Communication Interface Module

دليل المنتج：

1. JEOL BP101502-01 communication interface module builds a data transmission channel for the entire machine to the outside world
2. Control the timing of data transmission and reception to avoid data congestion during the transmission process
3. Built in filtering structure to weaken interference caused by external electromagnetic signals
4. Snap on fixed installation, disassembly and maintenance do not require extensive disassembly
5. The overall power consumption is low under no-load and full load conditions, and the temperature rise is not significant
6. Connect the scanning electron microscope host with the supporting external control terminal
7. The metal contacts are tightly interlocked, making it difficult for the equipment to experience instantaneous disconnection during vibration during operation
8. Compatible with the original driver program of the whole machine, it can be directly recognized and adapted after being connected

9. Independent channels respectively transmit control commands and collect detection data
10. Support real-time uploading and archiving of on-site semiconductor testing data
11. The circuit in the board is isolated by zones, and different transmission signals do not interfere with each other
12. Under normal indoor temperature and humidity conditions, it can work continuously 24/7
13. The surface solder mask layer blocks dust accumulation and reduces contact failure
14. Insulation cushion layer isolates high and low voltage lines to prevent damage to the circuit board caused by serial electricity
15. The JEOL BP101502-01 communication interface module has completed online testing and can be put into operation after assembly
The JEOL BP101502-01 communication interface module stably completes internal and external signal interconnection, with strong adaptability and easy daily maintenance.

صور مفصلة للمنتج：

BP101502-01
