JEOL BP102356-00 Control Pulse Card

دليل المنتج：

JEOL BP102356-00 Control Pulse Card
1. Compatible with JEOL precision equipment, JEOL BP102356-00 outputs control pulse signals for the drive motor
2. Filter external electromagnetic interference, and output stable and regular pulse signals
3. Electrical isolation protection to prevent high-voltage impact damage to board chips
4. Receive master control instructions and accurately output corresponding frequency pulse signals
5. High quality PCB substrate, not prone to circuit aging and faults when powered on for a long time
6. Slot direct insertion installation, من السهل تفكيكها واستبدالها
7. Sustainable and stable operation under normal temperature and humidity conditions in the computer room
8. Multiple pulse channels work independently and do not interfere with each other

9. Automatically activate hardware protection in case of abnormal current overload
10. The original factory welding is firm and resistant to equipment vibration, making it difficult for the welding to come off
11. Optimization of line impedance to reduce transmission loss of pulse signals
12. The overall power consumption is low, and the heat generated during operation is relatively small
13. Unified pin interface specifications, can directly replace the old JEOL BP102356-00
14. Factory debugging and testing of the entire machine, and it can be put into normal use after installation
15. Strong operational stability, suitable for long-term uninterrupted operation of instruments
JEOL BP102356-00 Control Pulse Card is an original matching card that provides stable pulse control for equipment motion positioning

صور مفصلة للمنتج：

BP102356-00
