JEOL CP002761-03 Central Processing Unit Module

دليل المنتج：

The JEOL CP002761-03 central processing unit module is compatible with the JSM-6701F scanning electron microscope and serves as the main control core board of the entire machine, coordinating the coordinated operation of various modules.
1. Original components, matched with JEOL JSM-6701F field emission scanning electron microscope
2. Execute the overall control program and schedule various functional boards
3. Receive operation instructions and issue control signals for vacuum, tube, and sample stage
4. Real time aggregation of sensor data to ensure stable imaging timing
5. Precise wiring to reduce signal crosstalk and avoid image interference

6. Slot type installation structure, التفكيك والاستبدال سهل وسريع
7. Anti static protection, protecting the onboard core computing chip
8. تصميم التدريع الكهرومغناطيسي, suitable for laboratory electromagnetic environment
9. Industrial grade components that support long-term continuous operation of instruments
10. Responsible for equipment fault self inspection and timely alarm of abnormal states
11. Integrated multiple overvoltage and overload circuit protection
12. The substrate is stable and reliable, and can withstand fluctuations in temperature and humidity environments
13. Equipped with a data storage unit to save instrument parameter configurations
14. Clear division of lines for easy fault detection and maintenance
15. Accurate dimensional tolerance, direct replacement without complex calibration
The JEOL CP002761-03 central processing unit module is responsible for the overall logic operation, instruction scheduling, and system control of the scanning electron microscope.

صور مفصلة للمنتج：

CP002761-03

فيديو المنتج
