JEOL TP000139-00 Printed Circuit Board

دليل المنتج：

JEOL TP000139-00 Printed Circuit Board
1. Compatible with JEOL precision electronic control system, JEOL TP000139-00 has low line transmission loss
2. High precision etching process, strict and controllable tolerance of circuit dimensions
3. High quality substrate resistant to high temperatures, supporting long-term continuous operation of instruments
4. Complete solder mask protection layer to prevent copper foil oxidation and short circuit
5. Solder pad size standard, component soldering is firm and reliable
6. Optimizing the electromagnetic characteristics of wiring to effectively reduce signal crosstalk
7. The board surface has good flatness and is not easily warped or deformed during installation

8. Unified positioning hole specifications, من السهل تفكيكها واستبدالها
9. JEOL TP000139-00 has stable insulation performance and can withstand voltage fluctuations
10. Specification for via fabrication, stable and durable multi-layer circuit conductivity
11. Clear silk screen markings on the circuit for easy maintenance and inspection of nodes
12. Adapt to changes in temperature and humidity inside the instrument, with strong environmental adaptability
13. The impedance parameters are preset by the factory and do not require secondary line adjustment
14. Having good anti vibration ability and adapting to equipment operating conditions
15. Original factory standard version, highly compatible with the supporting components of the entire machine
JEOL TP000139-00 printed circuit board is used as a circuit carrier substrate in various precision electronic and optical equipment of JEOL.

صور مفصلة للمنتج：

TP000139-00
