MATROX VIP-1024A Interface Module

دليل المنتج：

MATROX VIP-1024A Interface Module
مقدمة: Maichuang VIP-1024A is a VME bus image acquisition card used for visual image acquisition and processing in wafer inspection equipment.
VME standard board, single slot rack mounted, easy to disassemble and assemble
Three BNC video inputs, compatible with industrial camera analog signals
Built in 1024 × 1024 8-bit image cache, stable imaging storage
Supports two working modes: single frame capture and continuous acquisition
Equipped with zoom display function and multi window synchronized viewing of images
Synchronous signal output interface, matching device motion timing
A24/A32 bus addressing, compatible with various VME industrial control hosts
Hardware image preprocessing to reduce the computational load on the upper computer

Signal isolation filtering to resist electromagnetic interference and noise from equipment
Compatible with KLA wafer electron beam inspection machine original accessories
Onboard status indicator light for quick troubleshooting of image signal faults
Standard 24V DC power supply, matched with semiconductor equipment power supply
Multi layer shielded PCB wiring, image transmission without distortion or offset
Matched debugging program that can switch multiple video input sources
Factory image calibration, long-term detection with high consistency in imaging
خاتمة: MATROX VIP-1024A has stable image acquisition and is a core visual acquisition spare part for semiconductor wafer inspection equipment.

صور مفصلة للمنتج：

VIP-1024A
