Mega_f 00120-2000-000-04 Motion Controller

دليل المنتج：

Mega_f 00120-2000-000-04 Motion Controller
Mega_f 00120-2000-000-04 is a plug-in motion control board specifically designed for semiconductor precision platforms
200MHz floating point DSP core, 40kHz high-speed servo operation cycle
Support multi axis linkage, linear/circular interpolation, and extremely low positioning jitter
Compatible with various drives such as linear motors, voice coil motors, brushless servos, إلخ
Built in multi-stage vibration suppression filter to suppress mechanical resonance and reduce vibration
Supports encoder signals of sine cosine, incremental, and absolute values
Multiple communication interfaces including Ethernet, USB, and SPI for easy debugging at the upper level
Optical isolation limit, fault IO port, anti workshop electromagnetic interference

Three stage segmented gain adjustment, performance optimization in motion and tuning stages
Real time waveform display function, quick debugging of three loop control parameters
Multiple hardware safety protections including short circuit, الجهد الزائد, overheating, and emergency stop
معيار 19 inch rack card insertion, easy and quick disassembly and replacement
Metal shielding board, مقاوم للغبار والرطوبة, suitable for clean workshops
Large capacity storage, capable of storing multiple sets of equipment motion process programs
Suitable for crystal frustum, optical detection, and precision vacuum motion equipment
ملخص: Mega_f 00120-2000-000-04 has fast computation response, high positioning accuracy, and stable anti vibration, making it the core multi axis control unit of ultra precision semiconductor equipment.

صور مفصلة للمنتج：

00120-2000-000 -04
