Nexcom PEAK760VL2 Industrial Motherboard
دليل المنتج：
Nexcom PEAK760VL2 Industrial Motherboard
Nexcom PEAK760VL2 is a standard PICMG1.0 full-length card industrial motherboard, suitable for industrial automation and semiconductor equipment industrial control hosts, with stable operation and complete interfaces.
1. LGA775 slot, supporting Pentium 4 and Celeron D-series processors
2. 4 DDR2 memory slots, dual channel maximum support for 4GB memory
3. Equipped with dual Intel Gigabit Ethernet ports, supporting remote wake-up and PXE boot
4. مجهزة 4 SATA+1 IDE channels, compatible with multi specification storage devices
5. Comes with 6 sets of USB 2.0 و 2 RS232 serial ports, with ample external expansion
6. Integrated 4-in-4-out TTL digital IO, compatible with device signal control
7. 915GV+ICH6 chipset, integrated display core does not require separate display
8. Compatible with AT/ATX dual power supply, suitable for various industrial control chassis backboards
9. نطاق عمل واسع لدرجة الحرارة 0-60 درجه مئوية, resistant to high and low temperature workshop conditions
10. Full board industrial grade components, resistant to dust and electromagnetic interference
11. Compliant with RoHS environmental standards and suitable for clean process production lines
12. Full length card integrated structure, easy plug-in installation and maintenance
13. Onboard buzzing fault alarm, quickly locate hardware abnormalities
14. Supports PCI-E expansion slots and can be equipped with acquisition and communication expansion cards
15. تصميم دائرة منخفضة الطاقة, التشغيل المستمر على المدى الطويل ليس من السهل ارتفاع درجة حرارته
إجمالي, the Nexcom PEAK760VL2 industrial motherboard has strong expandability and good environmental adaptability, making it a universal core board for old industrial control equipment and semiconductor production line control hosts.
صور مفصلة للمنتج：
PEAK760VL2
