لوحة الحصول على الصور NI PCI-1424
دليل المنتج：
لوحة الحصول على الصور NI PCI-1424
مقدمة: NI PCI-1424 Industrial Digital Image Acquisition Board, compatible with semiconductor vision inspection equipment, capable of high-speed acquisition of grayscale and color images.
Single channel parallel digital input, compatible with both planar and linear industrial cameras
Up to 50MHz pixel clock, fast image transmission rate without frame loss
Onboard 16MB cache memory, supporting expansion, caching large format images
Supports 8-32-bit multi-level depth imaging, with clear image detail analysis
Provide 4-channel high-speed trigger IO, accurately synchronize camera acquisition timing
Divided into LVDS and RS422 signal versions, suitable for various digital cameras
Built in LUT lookup correction, real-time optimization of image grayscale color
Optocoupler isolation circuit, resistant to workshop electromagnetic interference and stable signal
PCI standard slot, easy to install by directly inserting into industrial control host
Equipped with NI-IMAQ driver and compatible with LabVIEW visual development software
Multiple hardware protection, anti-static, الجهد الزائد, surge damage to the board
Multi layer precision PCB wiring with low image data transmission loss
Industrial wide temperature element device, suitable for constant temperature operation environment in cabinets
Reserved detection points for convenient troubleshooting and signal debugging
Factory aging test for the entire machine, capable of continuous collection 24/7
خاتمة: NI PCI-1424 imaging acquisition is stable and compatible, ensuring the normal operation of the wafer appearance inspection visual system and reducing production line downtime faults.
صور مفصلة للمنتج：
PCI-1424
