PDP800 interface module

دليل المنتج：

PDP800 is the PROFIBUS DP interface module of ABB Symphony Plus system, used for high-speed communication connection between controllers and on-site intelligent devices.
Compatible with ABB Symphony Plus control system as a PROFIBUS DP master module.
Supports PROFIBUS DP V0/V1/V2 protocol and is compatible with third-party field devices.
The maximum communication speed is 12Mbps, supporting both electrical and fiber optic transmission media.
PROFIBUS PA instruments and actuators can be connected through DP/PA couplers.
Support 1ms high-precision timestamp for DP V2 to meet synchronous control requirements.
Support redundant configuration to enhance system communication reliability.
Power supply 24VDC, typical power consumption 3.6W, supports redundant power input.

A single bus can connect up to 64 slave devices, with a maximum fiber optic distance of 15km.
Integrated diagnostic port for easy on-site debugging and troubleshooting.
تصميم الصف الصناعي, درجة حرارة العمل -20 درجه مئوية~+60 درجه مئوية, protection level IP20.
Support S800 I/O access to the system via PROFIBUS DP.
Can be used in conjunction with controllers such as HPC800 and SPC700.
Support online configuration and firmware upgrade, من السهل الحفاظ عليها.
Compliant with IEC industry standards, suitable for harsh scenarios such as electricity and chemical industry.
هيكل وحدات, standard rail installation, التكامل العالي.
The PDP800, with its high-speed, مستقر, and compatible features, has become the core module for fieldbus communication in the Symphony Plus system.

صور مفصلة للمنتج：

PDP800
