PHOTON G29386-4021-002 Driver Analog Board

دليل المنتج：

PHOTON G29386-4021-002 Driver Analog Board for Semiconductor Device Power Drive Signal Acquisition and Conditioning

1. Collect driver current and voltage analog feedback signals
2. Built in signal filtering circuit to suppress workshop RF interference
3. Optocoupler isolates strong and weak electricity to prevent high voltage from damaging the main control channel
4. Amplify and calibrate the original signal to ensure stable sampling accuracy
5. Multiple sets of terminals are connected to the power unit and the main control backplane
6. The indicator light visually displays abnormal signals and circuit breaks
7. PHOTON G29386-4021-002 driver simulation board comes with parameter storage, and power-off configuration is not lost

8. Integrated overvoltage and reverse protection, voltage fluctuations are not easy to burn the board
9. Layered wiring distinguishes between power circuits and detection signal lines
10. Thickened through holes, less prone to breakage under alternating cold and hot working conditions
11. Welding point reinforcement ensures uninterrupted long-term vibration signals of the equipment
12. Standard slot insertion, الاستبدال المباشر لقطع الغيار من نفس الموديل
13. Reserve test points for maintenance without disassembling the entire drive system
14. ثلاثة طلاء مقاوم على سطح اللوحة, suitable for dust-free and corrosive gas environments
15. PHOTON G29386-4021-002 Drive Analog Board is compact in size, saving cabinet slots

PHOTON G29386-4021-002 driver analog board has stable signal acquisition and is a core detection board for RF/motor drive matching

صور مفصلة للمنتج：

G29386-4021-002
