Silicon Si5380 acquisition module

دليل المنتج：

Silicon Si5380 acquisition module
1. Xinke’s original high-precision clock acquisition timing module is commonly used in base stations and industrial control data acquisition equipment
2. Equipped with fourth generation DSPLL digital phase-locked technology, ultra-low phase noise, and suppression of clock jitter interference
3. Four independent clock inputs, input range 10MHz~750MHz, suitable for multi-source reference signal acquisition
4. Integrated 12 programmable clock outputs, supporting JESD204B protocol, matching ADC/DAC sampling timing
5. Built in non-volatile storage NVM, automatically loads configuration parameters when powered on, no need for repeated debugging
6. I2C/SPI dual line communication, external software can rewrite frequency and phase parameters online
7. Eliminating external VCXO and loop filtering devices, integrated design simplifies peripheral circuits

8. Multi level power supply compatible with 1.8V/2.5V/3.3V, suitable for different industrial control backplane voltage specifications
9. Single output phase independent fine-tuning, step size<20ps, precise alignment of multi-channel acquisition timing
10. Equipped with a power off hold mode, the sampling clock output remains stable even when the reference is lost
11. Three proof process for board surface, resistant to power clutter interference, and stable continuous operation in industrial computer rooms
12. Standard card mounting structure, gold finger slot directly inserted into the cabinet backplane, من السهل تفكيكها واستبدالها
13. A single module can replace multiple discrete crystal oscillators, reducing the overall BOM cost and space occupation of the machine

14. Original industrial components, stable wide temperature conditions, spare parts for maintenance of old RF acquisition equipment
15. Commonly used for clock synchronization acquisition scenarios in wireless base stations, data acquisition cards, and signal analyzers
في ملخص, the Silicon Si5380 acquisition module is the core timing matching component for devices to achieve multi-channel data sampling and clock synchronization acquisition.

صور مفصلة للمنتج：

Si5380
