سنفونيا SBX08-000089-1 لوحة الدوائر المطبوعة

دليل المنتج：

Sinfonia SBX08-000089-022 Printed Circuit Board Product Features
Sinfonia SBX08-000089-022 Semiconductor Equipment Servo Drive Main Control PCB
Integrated servo operation circuit, precise control of motor positioning action
Layered wiring of strong and weak electricity to reduce equipment RF interference
Multiple DI/DO signal channels, linked with machine sensors
Built in overcurrent and electrostatic protection, not easy to burn components
Large area copper foil heat dissipation, long-term high load without high temperature
Fully metalized via, stable signal transmission without open circuit

Thickened and reinforced solder pads, anti wind vibration without virtual soldering
High durability gold-plated gold fingers, stable insertion and removal contact
جهاز عنصر درجة الحرارة الصناعية واسعة, 24-hour mass production and stable operation
Independent signal filtering to avoid distortion of positioning data
Channel fault indicator light, easy maintenance and troubleshooting
فتحة لوحة الكترونية معززة قياسية, من السهل تفكيكها واستبدالها
Support bus communication, quickly connect devices to the upper level
Original factory matching circuit, with interchangeable Sinfonia boards of the same model
Sinfonia SBX08-000089-022 is the core circuit board for servo motion control of semiconductor precision equipment

صور مفصلة للمنتج：

SBX08-000089-1
