TEL 3D81-050028-V1 Printed Circuit Board

دليل المنتج：

TEL 3D81-050028-V1 Printed Circuit Board
مقدمة: TEL 3D81-050028-V1 is a PCB board specifically designed for semiconductor equipment, responsible for transmitting machine signals and power, and adapting to clean production conditions.
Multi layer high-density wiring, integrated with multiple control circuits
High temperature resistant substrate, able to withstand long-term high temperatures of the machine
Impedance optimization wiring to reduce signal transmission loss
Multi point grounding design to weaken external electromagnetic interference
Thickened conductive copper foil for stable power supply and low heat generation
Whole board solder mask coating, مقاوم للغبار, مقاوم للرطوبة, مقاومة للتآكل
Standard factory solder pads, compatible with various plug-in accessories
Partition signal isolation to prevent high and low voltage crosstalk

Multiple reserved testing points for convenient troubleshooting
Reinforced patch technology, less prone to virtual soldering during vibration
Clear screen printing on the board, making component assembly less prone to errors
Support high-speed signal transmission, process feedback without delay
Resistant to volatile gases in cleanrooms, delaying surface oxidation
Standard positioning hole position, no need to change the machine for replacement and disassembly
Factory aging full inspection, with few faults during long-term operation
خاتمة: TEL 3D81-050028-V1 line transmission is stable, ensuring the continuous and stable operation of the semiconductor machine control system and reducing the frequency of shutdown maintenance.

صور مفصلة للمنتج：

3D81-050028-V1

فيديو المنتج
