TEL TSB-PCB500002-01 Communication Control Board
دليل المنتج：
TEL TSB-PCB500002-01 communication control board is compatible with Tokyo Electronics wafer etching and deposition equipment, responsible for data exchange between various units of the machine
1. Equipped with a factory specific bus, it transfers process signals between the main control, chamber, and valve group
2. Optocoupler isolation circuit, shielding electromagnetic interference caused by radio frequency and motor
3. Synchronize the collection of data on flow, ضغط, and temperature, with low transmission delay
4. Multiple sets of standard interfaces, ربط أجهزة الاستشعار, driver modules, and safety circuits
5. ضوء مؤشر الخطأ على متن الطائرة, quickly locate disconnected or communication abnormal channels
6. PCB spraying dust-free three proof coating, resistant to workshop process volatile gases
7. TEL TSB-PCB500002-01 communication control board has built-in data cache, and short-term power failure parameters are not lost
8. Integrated surge and reverse protection, making communication channels less susceptible to damage from power grid fluctuations
9. Multi layer board with strong and weak electrical partition wiring, analog and digital signals do not interfere with each other
10. Thickened metalized through holes, less prone to circuit failure under cold and hot cycling conditions
11. Reinforce the solder pad process to maintain stable communication through continuous vibration of the equipment
12. Backboard direct insertion structure, spare parts of the same model can be directly replaced and installed
13. Reserve maintenance and testing points to troubleshoot without disassembling the cavity
14. Wide temperature tolerance design, the cabinet can operate continuously for a long time in high temperature environments
15. TEL TSB-PCB500002-01 communication control board standard board size, saving cabinet slot space
TEL TSB-PCB500002-01 communication control board has stable data exchange and is a core communication spare part for 300mm wafer process equipment
صور مفصلة للمنتج：
TSB-PCB500002- 01
