UFC721AE101 3BHB002916R0101 High Voltage Inverter Accessories
دليل المنتج：
Basic Information
نموذج: UFC721AE101
Part number: 3BHB002916R0101
Manufacturer: ABB
فئة: High Voltage Inverter Control/Interface Module
غاية: Control and signal interface for inverters in industrial automation systems
Function and Features
Acting as a control unit or I/O interface module in high-voltage inverter systems
Receive on-site sensor signals, process and output control commands
Communicate with the main controller (PLC/DCS) or drive system to achieve real-time data exchange
Support industrial communication protocols such as PROFIBUS, Modbus, إلخ
Designed for industrial environments, capable of withstanding high temperatures, رطوبة, والتداخل الكهرومغناطيسي
Technical specifications (typical)
Power input: 24V DC
Output signal: digital/analog signal output, used to control drivers or inverters
واجهة الاتصالات: serial interface or industrial bus protocol
Working temperature: -40 ° C to+70 ° C
القدرة على التكيف البيئي: مكافحة التدخل, رطوبة 5-95% (non condensing)
Size and weight: Industrial grade board specifications, compact size, weight approximately 0.3-0.5 kg
سيناريوهات التطبيق
High voltage inverter system control
Industrial Drivers and Motor Control
Remote I/O Expansion of Distributed Control Systems (DCS/PLC)
Industrial automation production lines, power and energy systems, robot control
Structure and Composition
UFC721AE101: Module model, core control/interface functions
3BHB002916R0101: Part number corresponding to the main control/interface board
The main task is to collect on-site signals, execute control logic, and communicate with the system
Can be combined with other ABB modules to achieve system expansion and redundant control
UFC721AE101 3BHB002916R0101 صور مفصلة للمنتج：
