1746-OB16 DC output module

Product Manual：

1746-OB16 is a commonly used DC output module in the Rockwell SLC500 series, widely used in industrial control systems, with stable and reliable operation.
1. Equipped with 16 DC output points and sufficient output capacity
2. Adopting leakage output mode, suitable for mainstream load devices
3. Standard backplane installation, compatible with all SLC500 series racks
4. Single channel independent control, clear division of labor in the circuit
5. Equipped with photoelectric isolation, effectively resisting electromagnetic interference
6. Each channel is equipped with status indicator lights for easy viewing of operating conditions
7. Quick response speed, precise and efficient instruction execution
8. Grouping circuit design, local faults do not affect each other
9. Built with industrial grade components for stronger durability

10. Low power design, suitable for long-term continuous operation
11. Equipped with overload and short circuit basic protection mechanism
12. Compact structure, reasonably saving installation space inside the cabinet
13. The wiring layout is well-organized, making later maintenance more convenient
14. Adapt to various complex industrial environments, resistant to temperature and vibration
15. Mostly used for controlling assembly lines and automated mechanical equipment
The 1746-OB16 DC output module has mature performance and is the core commonly used module for controlling DC load actions in the SLC500 control system.

Product detailed pictures：

1746-OB16

product video
