3BHB000272R0001 UFC719AE01 I/O interface driver board
Product Manual：
3BHB000272R0001 UFC719AE01 I/O interface driver board, ABB IOEC interface board, compatible with Advant Master and ACS1000 high-voltage frequency converters, completes the interaction between the main control and on-site I/O signals.
1. Integrate digital and analog signal transmission and reception, and connect with the external control circuit of the frequency converter
2. Supports Masterbus300 bus to achieve high-speed communication with the main control unit
3. Multiple DI/DO terminals, receiving switch commands and outputting status feedback
4. Analog channel, receiving 4-20mA signal and outputting control instructions
5. Channel electrical isolation to resist on-site surge electromagnetic interference
6. Panel LED indicator light, displaying power, communication, and channel fault status
7. Onboard hardware self diagnosis, quick identification of fault codes and issues
8. Support module hot plugging and online maintenance to reduce downtime
9. 24VDC DC power supply, stable power consumption, suitable for cabinet power supply
10. Coating protection process, suitable for dusty and humid industrial environments
11. Terminal block wiring, convenient on-site wiring and debugging
12. Configurable signal filtering to suppress on-site signal jitter
13. Compatible with system configuration software, online parameter modification and download
14. Rack slot installation, compatible with system chassis base
15. Industrial wide temperature range, suitable for high-voltage variable frequency working conditions in power plant metallurgy
3BHB000272R0001 UFC719AE01 is commonly used in high-voltage frequency conversion and DCS systems to handle frequency converter start stop, interlocking, and process given signals
