61-12225900-3A0094 Dual Channel Switch Controller
Product Manual：
61-12225900-3A0094 Dual Channel Switch Controller
Opening: 61-12225900-3A0094 is a dedicated dual channel switch control board for semiconductor equipment, which independently controls the on/off of two loads.
Dual channel independent control, two circuits do not interfere with each other, can drive valves and heaters separately
Channel with photoelectric isolation to isolate RF and plasma electromagnetic interference
Built in multiple hardware protections for overcurrent, short circuit, and overheating
Real time feedback switch status signal, uploaded to the equipment control system
Channel equipped with status indicator lights, quickly locate faulty channels
Backplane bus direct insertion installation, easy disassembly and replacement of spare parts
Gold plated pad design, stable contact for long-term use in dust-free workshops
PCB sprayed with a three proof coating, dustproof and moisture-proof, suitable for clean production lines
Precise wiring, control signal transmission without attenuation or crosstalk
Reinforced substrate material, capable of withstanding continuous vibration conditions of equipment
Reserved testing points for easy troubleshooting and troubleshooting
24V standard industrial power supply, low power consumption, long-term operation, low temperature rise
Support remote communication commands, PLC can remotely control on/off timing
Can store multiple sets of switch timing process parameters and call them with one click
Suitable for etching, thin film deposition, and wafer cleaning semiconductor equipment
Conclusion: 61-12225900-3A0094 dual channel control is stable, anti-interference and reliable, and the semiconductor equipment load on/off control core board.
Product detailed pictures：
61-12225900-3A0094
