ACS CM-2-B-E-M0-XY Motion Control Module

Product Manual：

ACS CM-2-B-E-M0-XY Motion Control Module
Introduction: ACS CM-2-B-E-M0-XY two axis integrated servo controller, suitable for XY gantry precision platform, dedicated for semiconductor vision positioning.
Built in dual axis servo drive, compatible with linear and rotary servo motors
20kHz high-speed servo sampling, smooth start stop without shaking
Equipped with gantry decoupling algorithm, XY synchronous positioning accuracy is high
Support multiple motion modes such as point positioning, interpolation, and master-slave following
Dual communication of Ethernet and serial port, fast docking with industrial control host
Integrated simple PLC, capable of processing sensor trigger signals
Built in vibration suppression function to eliminate mechanical resonance offset

Complete protection circuit, automatic shutdown for overcurrent, overvoltage, and short circuit
24V DC power supply, can supply power to encoders and sensors
Support HSSI expansion, can be externally driven to expand the number of axes
Nano level positioning resolution, suitable for high-precision detection processes
Compact metal body, space saving cabinet installation
Industrial wide temperature components, stable operation of high and low temperatures in the workshop
Equipped with specialized debugging software, parameter tuning and maintenance are convenient
Standard installation size, can be directly replaced with the same model
Conclusion: ACS CM-2-B-E-M0-XY synchronous control is stable and precise in positioning, and is commonly used for wafer inspection and optical precision platforms.

Product detailed pictures：

CM-2-B-E-M0-XY

product video
