ACS SB-14221-104 Motion Control Module
Product Manual：
ACS SB-14221-104 Motion Control Module
ACS SB-14221-104 is a motion control board specifically designed for semiconductor precision stages, with precise axis control and stable operation, suitable for photolithography detection equipment.
1. Equipped with ACS servo system, high hardware adaptability
2. Equipped with ServoBoost algorithm, automatic compensation for load fluctuations
3. Nano level positioning accuracy, extremely low motion tracking error
4. Support multi axis synchronous linkage, smooth trajectory without shaking
5. Built in vibration suppression algorithm to weaken platform resonance interference
6. LF halogen-free board meets the environmental standards of dust-free workshops
7. High speed Ethernet communication with low latency for instruction transmission
8. Multi channel isolated digital IO, compatible with various sensors
9. Multiple protection against overvoltage, overcurrent, and short circuit, self-locking shutdown due to fault
10. Compact board, rail installation saves cabinet space
11. 24V wide voltage supply, able to withstand voltage fluctuations in the workshop
12. Fully shielded circuit to resist radio frequency electromagnetic interference
13. Soft limit safety control to prevent platform collision
14. Standard plug-in interface, easy and efficient disassembly and maintenance
15. Industrial wide temperature design, capable of long-term uninterrupted operation
In summary, the ACS SB-14221-104 motion control module has high precision, anti vibration durability, and is the core control component of the semiconductor precision displacement platform.
Product detailed pictures：
SB-14221-104
