ACS SB-18422-660 Motion Control Board
Product Manual：
ACS SB-18422-660 Motion Control Board
Introduction: ACS SB-18422-660 is a multi axis servo control board specifically designed for semiconductor precision platforms
Equipped with a dedicated vibration suppression motion algorithm, high-speed operation suppresses platform resonance jitter
Compatible with incremental and absolute encoders, high-precision reading of position signals
Multi channel digital IO interface, compatible with limit, alarm, and interlock sensing signals
Ethernet high-speed communication, low latency transmission of motion commands and data
Support automatic PID tuning, quickly adapt to linear and rotary servo motors
Multi layer shielded PCB routing to resist production line RF electromagnetic interference
Sinking gold signal contact, stable and not easily oxidized after long-term plugging and unplugging
Integrated multiple hardware protections for overcurrent, overvoltage, overload, and short circuit
Standard industrial control slot specifications, directly plug and replace with the same model
Onboard status indicator light, quickly identify communication and fault status
Low speed motion without drift, positioning repeatability meets nanometer level requirements
Reserved debugging and testing points, convenient on-site parameter calibration
Industrial high-temperature resistant components, supporting 7 × 24-hour uninterrupted operation
Compact board size, saving installation space inside equipment cabinets
Suitable for wafer inspection, laser processing, and optical alignment precision equipment
Conclusion: ACS SB-18422-660 has high precision in motion control, smooth operation, and spare parts for high-precision automation equipment core boards
