ADAS STB 504 Bus Signal Expansion Board
Product Manual：
ADAS STB 504 Bus Signal Expansion Board
ADAS STB 504 is used for bus port expansion and signal forwarding, expanding system communication capabilities and ensuring stable and reliable operation.
lass=”yoast-text-mark” />>Belonging to the STB series expansion board, it focuses on bus interface expansion
Multi channel interface parallel output, capable of connecting more lower level devices and modules externally
Built in signal amplification circuit to compensate for signal loss caused by long-distance transmission
The channels are electrically isolated from each other, effectively preventing signal crosstalk issues
Equipped with surge and electrostatic protection to avoid hardware damage caused by circuit abnormalities
Independent indicator light group, providing feedback on working status and fault information one by one
The board surface adopts a three proof process, which is dustproof, moisture-proof, and oil resistant, suitable for industrial sites
Standard board size, compatible with mainstream chassis, easy to disassemble and replace
Reinforced panels and welding points, strong seismic resistance, suitable for high-frequency vibration equipment
Fully compatible with ADAS boards of the same series, flexible and convenient system expansion
Industrial grade component material, anti-aging, supporting all-weather continuous operation
Excellent power consumption performance, low temperature rise during full load operation, and low maintenance pressure
ADAS STB 504 bus signal expansion board is an important accessory for expanding bus nodes and extending communication links in industrial control systems.
Product detailed pictures：
STB 504
