ADLINK CPCI-6503VED Single Board Computer

Product Manual：

ADLINK CPCI-6503VED Single Board Computer
Opening: ADLINK CPCI-6503VED is a 3U CPCI reinforced industrial single board computer, suitable for harsh industrial embedded control scenarios.
Equipped with Core 6 processor, the computing performance is sufficient and stable
Dual channel DDR4 memory, supporting up to 32GB of high-capacity RAM
Multi channel independent display output, capable of synchronized operation across multiple screens
Dual Gigabit Ethernet ports, high-speed transmission of industrial data without buffering
Multiple sets of SATA high-speed storage interfaces for convenient expansion of storage
Rich USB 3.0/2.0 interfaces, flexible access to peripherals
Built in SEMA intelligent embedded hardware management function

Stable operation at a wide temperature range of -40 ℃~85 ℃, resistant to high and low temperatures
Standard CPCI 3U specification, chassis rail plug-in installation
Full board reinforced anti vibration, suitable for vehicle mounted and semiconductor equipment
Onboard hardware watchdog, automatic restart and recovery in case of abnormalities
Complete wiring I/O design, clean cabinet wiring
Multiple overvoltage and overcurrent circuit protection to reduce hardware damage
Compatible with various industrial control systems such as Windows and Linux
Long life cycle industrial components reduce equipment maintenance
Conclusion: ADLINK CPCI-6503VED single board computer has sufficient computing power and strong environmental adaptability, making it the core board for industrial measurement and control and equipment control.

Product detailed pictures：

CPCI-6503VED
