ADLINK TECHNOLOGY 02EM4-SD6G560 Printed Circuit Board
Product Manual：
ADLINK TECHNOLOGY 02EM4-SD6G560 Printed Circuit Board
Opening: ADLINK 02EM4-SD6G560 is a dedicated main control PCB for Linghua Industrial embedded devices, suitable for machine vision and automation industrial control hosts
Multi layer impedance matching circuit, supporting DDR5 5600 high-speed memory stable transmission
Sinking gold pad technology, contact anti-oxidation, long-term plug-in contact stability
Built in complete power supply layer, effectively suppressing high-speed signal crosstalk interference
Strong and weak current zoning wiring, high and low voltage isolation to reduce the risk of short circuit leakage
Industrial high temperature resistant FR4 substrate, continuous operation under wide temperature conditions without deformation
Standard COM Express specification positioning hole, directly replace modules of the same specification
Reserve multiple sets of signal testing points for convenient and fast fault maintenance and detection
Onboard multi-channel filtering circuit ensures the purity of image and communication signals
The pin identification of silk screen components is clear, and the disassembly and wiring are not prone to errors
Reinforce the sheet structure to prevent welding and wire breakage in the vibration environment of the production line
Dustproof solder mask coating reduces workshop dust erosion on the circuit
Multi channel high-speed expansion interface wiring, compatible with visual acquisition peripherals
Multiple circuit protection, electrostatic and surge automatic protection chip
Original factory machine aging test, continuous operation for 7 × 24 hours with low faults
Compact board design, suitable for small industrial control chassis installation space
Conclusion: ADLINK 02EM4-SD6G560 has stable high-speed signals and strong compatibility, and is a spare part for core circuits of industrial vision and automation equipment
Product detailed pictures：
02EM4-SD6G560
