Alstom VDG14AF9001ACH displacement relay

Product Manual：

Alstom VDG14AF9001ACH displacement relay
1. Monitor mechanical displacement and achieve position over limit protection output
2. Mechanical displacement detection triggers corresponding switch contact actions
3. Installation of rail rack, easy disassembly, debugging, and maintenance operation
4. Adjustable action threshold, suitable for different displacement protection ranges
5. Adequate contact capacity, directly driving the interlocking control circuit
6. Fast response speed, quick triggering of protection for abnormal displacement
7. Equipped with a mechanical reset structure, it is easy to recover after troubleshooting
8. Industrial shell protection, anti vibration and adaptable to on-site working conditions

9. Wide temperature working range, stable operation in high and low temperature environments
10. EMC electromagnetic protection, resistant to on-site electromagnetic interference
11. Stable mechanical structure with minimal drift during long-term operation
12. Intuitive status indication for easy on-site fault diagnosis
13. Compact structure, saving internal space of control cabinet
14. Multiple units can be combined to achieve multi-point displacement monitoring and protection
15. Adaptive transmission and power equipment safety interlocking system
Alstom VDG14AF9001ACH displacement relay is a displacement monitoring and protection component commonly used in transmission equipment and power plant mechanical position interlock protection circuits.

Product detailed pictures：

VDG14AF9001ACH
