AMAT 0100-37981 Interface Board PCB
Product Manual：
AMAT 0100-37981 Interface Board PCB
Introduction: AMAT 0100-37981 is a dedicated interface PCB for semiconductor equipment SCR thyristor, and a spare part for signal transfer between the main control and power regulation units.
0100-37981 transmits voltage regulation commands and synchronously collects SCR operation feedback signals
Optoelectronic isolation circuit, isolating high-voltage plasma interference and protecting the main control circuit
Multiple sets of high-density DB terminals, compatible with power module wiring docking
Built in filtering circuit, suppresses clutter, and ensures stable power output without fluctuations
Partition status indicator light, quickly troubleshoot communication and voltage regulation abnormalities
Multi layer high current wiring, stable carrying power control signal transmission
Single circuit independent overcurrent and short-circuit protection to avoid power device burnout
Industrial temperature resistant components, supporting 24/7 uninterrupted process production
Standard chassis card insertion structure, disassembly and replacement without changing the circuit
Partition shielded wiring to reduce the impact of RF electromagnetic interference in the cavity
Three proof coating on the board surface, dustproof and moisture-proof, suitable for dust-free clean workshops
Closed loop sampling feedback ensures temperature control and sputtering power adjustment accuracy
Compatible with Centura and Endura thin film deposition and sputtering equipment platforms
Factory completed electrical calibration, directly matched with SCR power unit on the machine
Standard gold-plated connector, compatible with boards of the same model that can be directly interchanged
Conclusion: AMAT 0100-37981 is commonly used for power regulation of semiconductor sputtering and annealing equipment, with stable operation, and is a regular maintenance spare part for the machine.
Product detailed pictures：
0100-37981
