AP-2118A-S-PBF electronic board
Product Manual：
AP-2118A-S-PBF electronic board
AP-2118A-S-PBF is a lead-free PBF process industrial buck power circuit board, suitable for power conversion of semiconductor and precision automation equipment, with stable output, clean and durable.
1. Lead free and environmentally friendly PBF process, compliant with RoHS standards for use in clean rooms
2. Multi layer precision circuit layout with low signal voltage drop and high conduction efficiency
3. Equipped with synchronous voltage reduction circuit, continuously outputting 3A stable current
4. Output voltage accuracy ± 1.5%, with minimal load fluctuation
5. Supports PWM/PFM dual-mode, significantly reducing power consumption under light load conditions
6. Integrated soft start circuit, no high-voltage impact damage to components when powered on
7. Built in OVP/OCP/overheat/undervoltage quadruple circuit protection
8. Onboard EMI shielding layer to block workshop RF electromagnetic interference
9. 1.2MHz standard switching frequency, matched with small heat dissipation devices
10. High temperature resistant and flame-retardant substrate, not easily deformed during long-term full load operation
11. Gold finger plug-in interface, easy to install by inserting directly into the cabinet card slot
12. Immersion gold process contacts, anti-oxidation, long-term contact without voltage jump
13. Reserve multiple sets of testing points, and troubleshooting does not require dismantling the entire machine
14. Compact small board body, space saving installation inside the cabinet
15. Reinforced surface mount components, making it difficult to solder off in the vibration environment of the production line
In summary, the AP-2118A-S-PBF electronic board has precise power supply, comprehensive protection, and is clean and non-volatile, making it a core circuit accessory for small power conversion in industrial control and semiconductor equipment.
