AUE-1108 Embedded Excitation Card

Product Manual：

AUE-1108 Embedded Excitation Card
Dedicated to closed-loop regulation of excitation current for synchronous generators and motors
Embedded digital control, fast response and high adjustment accuracy
Realize automatic voltage regulation AVR, reactive power and power factor control
Fully isolated signal design, strong ability to resist on-site electromagnetic interference
Support input of analog, switch, and speed/position feedback signals
Built in multiple protections such as over excitation, under excitation, over-current, over-voltage, and grounding
Equipped with fault self diagnosis and status indication function
Wide temperature industrial grade design, suitable for harsh environments such as ships and power stations
Modular card insertion structure, easy to install and maintain
Support communication interface, capable of connecting to upper computer and control system
Compatible with the Kangshibo series control platform, with good compatibility
Long term stable operation and high reliability

Product detailed pictures：

AUE-1108

product video
