Autotech DM5-G0360-1P00 parser decoder
Product Manual：
Autotech DM5-G0360-1P00 parser decoder
1. Resolve to Digital rotary transformer signal decoding, converting analog rotary transformer signals into digital position signals
2. Single channel processing, matching 360 count per circle position resolution specifications
3. Proportional tracking decoding algorithm, strong noise resistance, stable position tracking
4. Supports binary and Gray code digital output, compatible with PLC and servo control systems
5. Installation of rail mounted cabinets, with wiring terminals for easy on-site wiring and debugging
6. Built in rotary transformer excitation output, directly providing excitation signals to the rotary transformer
7. Real time output of angle, speed and position data, fast response speed
8. Capable of detecting overspeed and abnormal position, and outputting alarm switch signals
9. Support programmable offset and proportional coefficient, convenient on-site zero calibration
10. Optoelectronic isolation interface, isolates on-site interference, protects backend controller
11. Wide DC power supply, suitable for industrial control cabinet power supply environment
12. Wide temperature working range, suitable for high and low temperature working conditions of industrial equipment
13. EMC electromagnetic compatibility, resistant to electromagnetic interference caused by frequency converters and motors
14. Panel status indicator light for intuitive viewing of operation and fault status
15. Compact size, saving installation space inside the control cabinet
Autotech DM5-G0360-1P00 parser decoder, rotary digital conversion unit, commonly used in servo presses, heavy industry drives, and motor angle and position acquisition systems.
