AVME-115A Printed Circuit Board
Product Manual：
AVME-115A Printed Circuit Board
AVME-115A is an industrial control printed circuit board based on VME bus under the AVAL DATA brand. As a 6U single slot VME module, it is used for data acquisition and system control in industrial automation, aerospace and other fields.
1. Standard B-size 6U single slot VME bus architecture, suitable for installation in VME industrial control chassis
2. Equipped with 2 channels of 25 pin female interfaces to meet the requirements of multi-channel signal transmission
3. Configure a 16 pin male head printer interface that supports external printing devices
4. Onboard RST reset button and ABT function button, convenient debugging operation
5. Equipped with status LED indicator lights, real-time display of operation and fault status
6. Industrial PCB material, good insulation, anti-aging, suitable for long-term working conditions
7. Strict impedance control, excellent signal integrity, and stable high-frequency transmission
8. Multi layer board design, high integration, regular wiring, strong resistance to electromagnetic interference
9. Wide temperature working ability, adaptable to complex high and low temperature environments in industrial sites
10. Gold plated process contacts, anti-oxidation, plug and unplug resistant, high connection reliability
11. Support hot swapping, maintenance without downtime, reducing system interruption risk
12. Compatible with AVAL DATA AVME-115x series firmware and drivers
13. Compliant with industrial safety certification, flame retardant characteristics meet standards, safe and reliable
14. Reinforced board structure, earthquake resistant and impact resistant, suitable for harsh working conditions
15. Original industrial grade quality, 7 × 24-hour continuous operation, low failure rate
The AVME-115A printed circuit board is an essential core component in the VME bus control system, with rich interfaces, stability, durability, and strong adaptability.
