BOBST 0701252401 Printed Circuit Board
Product Manual：
BOBST 0701252401 Printed Circuit Board
BOBST 0701252401 is the main control/driver PCB for Bost paste box/die-cutting/hot stamping equipment, responsible for system logic control, I/O drivers, and signal interaction, serving as the core control board for the equipment.
Original part number: 0701252401, BOBST original main control board, compatible with multiple models
Core functions: System logic operation, sensor signal processing, actuator drive control
Compatible models: NOVAFOLD series box gluing machine, SP series die-cutting machine, FOL series hot stamping machine
Industrial grade material: FR-4 high Tg flame-retardant plate, high temperature resistant and anti-aging
Multi layer board structure: 6-layer design, including power/signal/shielding layers, strong anti-interference
Precision circuit technology: line width and spacing ≤ 0.1mm, aperture ≤ 0.2mm, suitable for high-density components
Gold plated solder pads: contact edges and solder pads are gold-plated, anti-oxidation, and have a long insertion and removal life
Three proof protection: The entire board is coated with three proof paint to prevent moisture, dust, and corrosion
Wide temperature range: -25 ℃ to+75 ℃, suitable for complex temperature environments in the workshop
High integration design: onboard CPU, I/O interface, communication module, high integration
Status monitoring: multi-color LED indicator lights, intuitive power/operation/fault status
Standard installation: Original size and hole position, in-situ replacement, no modification required
Signal stability: low ripple, low noise, ensuring control accuracy and stability
Durable and reliable: industrial grade components, resistant to vibration and impact
Fully compatible: matches BOBST original firmware and communication protocol, can be replaced and used immediately
Product detailed pictures：
