BOSE 323984-0030 W Controller Module

Product Manual：

BOSE 323984-0030 W Controller Module Product Features
BOSE 323984-0030 W Commercial Audio System Dedicated Partition Control Board
Integrated audio signal adjustment circuit, precise control of partition volume and audio source switching
Built in signal noise reduction circuit to eliminate current noise generated by power amplifier transmission
Multiple independent control channels, multi area sound system without interference adjustment
Bus communication interface with digital audio processor, instruction response without delay
Onboard electrostatic protection components, which are not easily damaged by voltage fluctuations in the computer room
Small embedded board, compatible with amplifier chassis, compact built-in space

Gold plated pin interface, not prone to contact failure during long-term insertion and removal
Partition status indicator light, quickly locate single area control faults
Separate the routing of audio strong and weak lines to prevent signal crosstalk and distortion
Temperature resistant industrial PCB substrate for long-term stable operation in commercial settings
Thickened and reinforced solder joints to resist continuous vibration and detachment of equipment fans
Simple dialing to set partition addresses, no software required for on-site debugging
Low power circuit design, continuous operation with low temperature rise and no overheating hazard
Original factory matching circuit, BOSE audio equipment of the same model can be directly replaced
BOSE 323984-0030 W controller module is a core partition control accessory for commercial background music systems

Product detailed pictures：

323984-0030 W
