BP102019-00 Communication Module

Product Manual：

BP102019-00 Communication Module
1. BP102019-00 is responsible for the data transmission of various boards within the instrument
2. Comes with data verification to reduce data confusion and loss
3. Electrical isolation design to resist internal electromagnetic interference
4. Equipped with overcurrent protection, the module is not easily damaged due to abnormal wiring
5. Adapt to the original factory communication protocol, and once installed, it can be used normally
6. Card type installation, easy to disassemble and replace, convenient and convenient
7. The structure is sturdy and the connection is stable when the equipment vibrates

8. Moisture and dust prevention, suitable for the enclosed environment inside the instrument
9. Detectable communication disconnection for quick maintenance
10. Multi component data interoperability ensures smooth collaborative operation of the entire machine
11. Low power consumption, minimal heat generation during long-term operation
12. Precise wiring, stable transmission of weak signals
13. The channels are independent of each other, and a single fault does not result in a complete disconnection
14. Surface protection treatment, not easily oxidized or aged
15. Strict factory inspection, low failure rate in daily use
Overall, BP102019-00 has stable and reliable communication, making it a dedicated communication accessory for JEOL precision instruments.

Product detailed pictures：

BP102019-00

product video
