B&R 050005082-06 motherboard
Product Manual：
B&R 050005082-06 (APCBB5/6) Industrial Control Computer PCI Bus Backplane
1. 6 expansion slots, compatible with PCI/PCIe data acquisition and communication cards
2. Line partition shielding to reduce signal crosstalk
3. Gold plated socket contacts, stable insertion and removal without oxidation
4. Split fuse, single card fault protection for the entire machine
5. Thick copper foil, low temperature rise at full load for multiple trucks
6. Metallized via, low loss for high-speed data transmission
7. Reserved fan and temperature detection expansion interface
8. Suitable for the original industrial control chassis of Beijiale, with stable installation
9. High temperature resistant industrial board, long-term stable operation of workshop
10. Clear silk screen markings for easy maintenance and troubleshooting
11. Multi channel balanced power supply with small output ripple
12. Supports EtherCAT and POWERLINK industrial communication cards
13. Snap on slot, easy to disassemble and assemble the board
14. Double protection against short circuit and overcurrent, high safety
15. Original standard size, can be replaced directly without changing the program
B&R 050005082-06 bus backplane transmission is stable and commonly used spare parts for automation industrial control chassis.
Product detailed pictures：
050005082-06
product video
