COHERENT 0178-112-00 Pulse Laser Card
Product Manual：
COHERENT 0178-112-00 Pulse Laser Card
Introduction: COHERENT 0178-112-00 is compatible with Avia 355 ultraviolet laser and is a pulse output control core board. It is a spare part for equipment maintenance and replacement.
0178-112-00 Precise Control of Laser Pulse Frequency, Pulse Width, and Power
High speed timing circuit, fast light response, stable waveform without offset
Built in shielded circuit to resist electromagnetic interference in industrial environments
Multi channel signal feedback, real-time monitoring of laser operation status
Integrated overcurrent and over temperature multiple protections to prevent laser damage
Standard gold finger card insertion structure, easy disassembly and replacement of chassis
The status indicator light is intuitive and can quickly locate communication and pulse faults
Industrial grade chip components that support long-term continuous processing and operation
Dedicated bus interface, compatible with laser host main control communication
Board protective coating, dustproof and moisture-proof, suitable for dust-free processing workshops
Closed loop power correction, good consistency of long-term operation output
Onboard parameter storage, saving multiple sets of processing pulse formulas
Wide temperature circuit design, no drift in performance under high and low temperature conditions
Multi layer precision wiring, low loss of high-frequency pulse signals
Original factory calibration, directly matched with laser machine on the machine
Conclusion: COHERENT 0178-112-00 is widely used in semiconductor precision processing UV laser equipment, with stable and reliable pulse control.
Product detailed pictures：
0178-112-00
