COHERENT 1099146-DA Controller Module

Product Manual：

COHERENT 1099146-DA laser controller controls laser power and operating timing

1. Stable regulation of laser power to ensure processing and detection accuracy
2. Both digital and analog signals can be connected to the main control of the device
3. Overheating, overload, and interlock faults will automatically shut down the laser
4. Real time collection of operational data such as power and temperature
5. Indicator lights distinguish between operating and fault states
6. Circuit board anti-corrosion and moisture-proof, suitable for dust-free workshops
7. COHERENT 1099146-DA can save multiple sets of process parameters without losing them during power outages

8. Isolation circuit to resist accidental triggering of equipment electromagnetic interference
9. Separate strong and weak electrical lines, without affecting each other’s signals
10. Thickened circuit holes make it difficult to break wires in temperature difference environments
11. The welding points are firm and the equipment can work stably even under vibration
12. Standard slot, directly replace with spare parts of the same model
13. Reserve detection points for easy maintenance without dismantling the entire machine
14. High temperature resistance, supporting uninterrupted operation throughout the day
15. COHERENT 1099146-DA is compact in size, saving cabinet space
COHERENT 1099146-DA has stable and safe control, and is commonly used in wafer laser detection equipment

Product detailed pictures：

1099146-DA

product video
